Commercial meat grinders
Meat grinder MIM-1000
ORDER
Characteristics
Weight (kg, maximum)
211
Height (mm)
1100
Width (mm)
600
Length (mm)
1225
Current frequency (Hz)
50
Rated voltage (V)
380
Type of current
three - phase, alternating
Tray volume (L)
40
Rated power consumption (KW)
6.5
Installed power (KW)
5.5
Performance (kg/h, minimum)
1000
Description
<p>MIM-1000 meat grinder is designed for mincing blocks of trimmed meat for production of sausages and other meat products </br> - at catering facilities, </br> - in meat store and small production shops, </br> - meat shops of stores</br> - at enterprises producing patties, dumplings, sausages or other semi-finished products. </p>
<p>Grinder provides the “Reverse” mode in case of auger stopping during processing of low-quality meat products. </p> <p>Machine is manufactured from high quality stainless steel. </p> <p>It has double transmission technology: </br> electric motor - chain drive - belt drive - intermediate shaft - drive shaft. </p>
<p>Machine is equipped with “Enterprise” removable system of blades and grinding plates made of high-quality material providing resistance to damage. </p> <p>Ventilated 3-phase motor ensures continuous uninterrupted operation with no necessity of special maintenance. </p> <p>Warranty period is 24 months. It starts from the day of putting the machine into operation, but not later than 6 months from the date of machine purchase. </p>
Certificates
System
<p>1 - Meat mincer; </p> <p>2 - Electric motor; </p> <p>3 - Nut; </p> <p>4 - "Start" button; </p> <p>5 - "Stop" button; </p> <p>6 - "Reverse" button; </p> <p>7 - Tray with protection element; </p> <p>8 - Pusher; </p> <p>9 - Wheels; </p> <p>10 - Chain drive; </p> <p>11 - Belt drive; </p> <p>12 - Facing; </p> <p>13 - Control unit. </p>
